INVT IPE300 Series User Manual

IPE300 series engineering VFD Dimension drawings
-344-
C.4.3 Floor installation dimensions (unit: mm)
W4
W2
W2
H1
H2
D1
W1
W3
D2
D2
3- ø13.0
6- ø12.0
Figure C-13 Floor installation diagram for 380V 0220–0315 models
VFD model
Outer dimension (mm)
Installation dimension (mm)
Hole diameter
(mm)
Fixing
screw
W1
H1
D1
W4
W2
W3
H2
D2
0220–0315
750
1410
380
680
230
714
1390
150
13/12
M12/M10
W1
W2
W2
H1
H2
3- ø22.0
D1
D2
D2
W3
6- ø12.0
Figure C-14 Floor installation diagram for 380V 0355–0500 models
VFD model
Outer dimension (mm)
Installation dimension (mm)
Hole diameter
(mm)
Fixing
screw
W1
H1
D1
W4
W2
W3
H2
D2
0355–0500
620
1700
560
-
230
572
1678
240
22/12
M20/M10
