INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-201-
Function
code
Name
Description
Default
Modify
P19.03
Software version
of card at slot 1
0.00–655.35
0.00
●
P19.04
Software version
of card at slot 2
0.00–655.35
0.00
●
P19.05
Software version
of card at slot 3
0.00–655.35
0.00
●
P19.06
Terminal input
status of I/O card
0–0xFFFF
0
●
P19.07
Terminal output
status of I/O card
0–0xFFFF
0
●
P19.08
HDI3 input
frequency of I/O
card
0.000–50.000kHz
0.000
kHz
●
P19.09
AI3 input voltage
of I/O card
0.00–10.00V
0.00V
●
P19.10–P
19.39
Reserved
0–65535
0
●
P20 group––Encoder of motor 1
Function
code
Name
Description
Default
Modify
P20.00
Encoder type
display
0: Incremental encoder
1: Resolver-type encoder
2: Sin/Cos encoder
3: Endat absolute encoder
0
●
P20.01
Encoder pulse
number
Number of pulses generated when the encoder
revolves for one circle.
Setting range: 0–60000
1024
◎
P20.02
Encoder
direction
Ones place: AB direction
0: Forward
1: Reverse
Tens place: Z pulse direction (reserved)
0: Forward
1: Reverse
Hundreds: CD/UVW pole signal direction
0: Forward
1: Reverse
0x000
◎
P20.03
Detection time of
encoder offline
fault
Indicates the detection time of encoder offline
fault.
Setting range: 0.0–10.0s
1.0s
○
