IPE300 series engineering VFD Function parameter list
-146-
Function
code
Name
Description
Default
Modify
P05.44
HDIB high-speed
pulse input
function
selection
0: Input set through frequency
1: Reserved
2: Input set through encoder, used together with
HDIA
0
◎
P05.45
HDIB lower limit
frequency
0.000 kHz – P05.47
0.000
kHz
○
P05.46
Corresponding
setting of HDIB
lower limit
frequency
-100.0%–100.0%
0.0%
○
P05.47
HDIB upper limit
frequency
P05.45–50.000kHz
50.000
kHz
○
P05.48
Corresponding
setting of HDIB
upper limit
frequency
-100.0%–100.0%
100.0%
○
P05.49
HDIB frequency
input filter time
0.000s–10.000s
0.030s
○
P05.50
AI1 input signal
type
0: Voltage
1: Current
Note: You can set the AI1 input signal type
through the corresponding function code.
0
◎
P05.51–P
05.52
Reserved
0–65535
0
●
P06 group––Output terminals
Function
code
Name
Description
Default
Modify
P06.00
HDO output type
0: Open collector high-speed pulse output. The
max. frequency of pulse is 50.00kHz. For details
about the related functions, see P06.27–P06.31.
1: Open collector output. For details about the
related functions, see P06.02.
0
◎
P06.01
Y1 output
0: Disable
1: Running
2: Running forward
3: Running reversely
4: Jogging
0
○
P06.02
HDO output
0
○
P06.03
Relay RO1
output
1
○
P06.04
Relay RO2
5
○
