INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-145-
Function
code
Name
Description
Default
Modify
P05.34
Corresponding
setting of AI2
middle value 2
input. Increasing the value properly can enhance
analog input anti-interference but may reduce the
sensitivity of analog input.
Note: AI1 supports the 0–10V/0–20mA input.
When AI1 selects the 0–20mA input, the
corresponding voltage of 20mA is 10V. AI2
supports the -10–+10V input.
P05.24 setting range: 0.00V–P05.26
P05.25 setting range: -100.0% –100.0%
P05.26 setting range: P05.24–10.00V
P05.27 setting range: -100.0% –100.0%
P05.28 setting range: 0.000s–10.000s
P05.29 setting range: -10.00V–P05.31
P05.30 setting range: -100.0% –100.0%
P05.31 setting range: P05.29–P05.33
P05.32 setting range: -100.0% –100.0%
P05.33 setting range: P05.31–P05.35
P05.34 setting range: -100.0% –100.0%
P05.35 setting range: P05.33–10.00V
P05.36 setting range: -100.0% –100.0%
Setting range of P05.37: 0.000s–10.000s
0.0%
○
P05.35
AI2 upper limit
10.00V
○
P05.36
Corresponding
setting of AI2
upper limit
100.0%
○
P05.37
AI2 input filter
time
0.030s
○
P05.38
HDIA high-speed
pulse input
function
selection
0: Input set through frequency
1: Reserved
2: Input set through encoder, used together with
HDIB
0
◎
P05.39
HDIA lower limit
frequency
0.000 kHz – P05.41
0.000
kHz
○
P05.40
Corresponding
setting of HDIA
lower limit
frequency
-100.0%–100.0%
0.0%
○
P05.41
HDIA upper limit
frequency
P05.39–50.000kHz
50.000
kHz
○
P05.42
Corresponding
setting of HDIA
upper limit
frequency
-100.0%–100.0%
100.0%
○
P05.43
HDIA frequency
input filter time
0.000s–10.000s
0.030s
○
