Function
code
Name
Description
Default
P07.45
Bus voltage at last fault
0.0V
P07.46
Max. temperature at last fault
0.0°C
P07.47
Input terminal status at last
fault
0
P07.48
Output terminal status at last
fault
0
P07.49
Running frequency at 2nd-last
fault
0.00Hz
P07.50
Ramp reference frequency at
2nd-last fault
0.00Hz
P07.51
Output voltage at 2nd-last
fault
0V
P07.52
Output current at 2nd-last
fault
0.0A
P07.53
Bus voltage at 2nd-last fault
0.0V
P07.54
Max. temperature at last 2
fault
0.0°C
P07.55
Input terminal status at
2nd-last fault
0
P07.56
Output terminal status at
2nd-last fault
0
5.5.17 Profibus-DP free programming function
5.5.17.1 Profibus-DP state machine
Profibus-DP meets the state machine logic as shown in the following figure when communicating.
