IPE300 series engineering VFD Optional peripheral accessories
-362-
D.7.2 Filter model selection
Table D-7 AC 3PH 380V (-15%)–440V (+10%)
VFD model
Input filter
Output filter
IPE300-01R5-4
FLT-P04006L-B
FLT-L04006L-B
IPE300-02R2-4
IPE300-0004-4
FLT-P04016L-B
FLT-L04016L-B
IPE300-05R5-4
IPE300-07R5-4
FLT-P04032L-B
FLT-L04032L-B
IPE300-0011-4
IPE300-0015-4
FLT-P04045L-B
FLT-L04045L-B
IPE300-0018-4
IPE300-0022-4
FLT-P04065L-B
FLT-L04065L-B
IPE300-0030-4
IPE300-0037-4
FLT-P04100L-B
FLT-L04100L-B
IPE300-0045-4
IPE300-0055-4
FLT-P04150L-B
FLT-L04150L-B
IPE300-0075-4
IPE300-0090-4
FLT-P04240L-B
FLT-L04240L-B
IPE300-0110-4
IPE300-0132-4
IPE300-0160-4
FLT-P04400L-B
FLT-L04400L-B
IPE300-0185-4
IPE300-0200-4
IPE300-0220-4
FLT-P04600L-B
FLT-L04600L-B
IPE300-0250-4
IPE300-0280-4
IPE300-0315-4
FLT-P04800L-B
FLT-L04800L-B
IPE300-0355-4
IPE300-0400-4
IPE300-0450-4
FLT-P041000L-B
FLT-L041000L-B
IPE300-0500-4
Note:
1. The input EMI meets the C2 requirements after an input filter is configured.
2. The preceding table describes external accessories. You need to specify the ones you choose
when purchasing accessories.
