INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-98-
Function
code
Name
Description
Default
P10.10
Multi-step speed 4
-100.0–100.0%
0.0%
P10.11
Running time of step 4
0.0–6553.5s (min)
0.0s
P10.12
Multi-step speed 5
-100.0–100.0%
0.0%
P10.13
Running time of step 5
0.0–6553.5s (min)
0.0s
P10.14
Multi-step speed 6
-100.0–100.0%
0.0%
P10.15
Running time of step 6
0.0–6553.5s (min)
0.0s
P10.16
Multi-step speed 7
-100.0–100.0%
0.0%
P10.17
Running time of step 7
0.0–6553.5s (min)
0.0s
P10.18
Multi-step speed 8
-100.0–100.0%
0.0%
P10.19
Running time of step 8
0.0–6553.5s (min)
0.0s
P10.20
Multi-step speed 9
-100.0–100.0%
0.0%
P10.21
Running time of step 9
0.0–6553.5s (min)
0.0s
P10.22
Multi-step speed 10
-100.0–100.0%
0.0%
P10.23
Running time of step 10
0.0–6553.5s (min)
0.0s
P10.24
Multi-step speed 11
-100.0–100.0%
0.0%
P10.25
Running time of step 11
0.0–6553.5s (min)
0.0s
P10.26
Multi-step speed 12
-100.0–100.0%
0.0%
P10.27
Running time of step 12
0.0–6553.5s (min)
0.0s
P10.28
Multi-step speed 13
-100.0–100.0%
0.0%
P10.29
Running time of step 13
0.0–6553.5s (min)
0.0s
P10.30
Multi-step speed 14
-100.0–100.0%
0.0%
P10.31
Running time of step 14
0.0–6553.5s (min)
0.0s
P10.32
Multi-step speed 15
-100.0–100.0%
0.0%
P10.33
Running time of step 15
0.0–6553.5s (min)
0.0s
P10.34
ACC/DEC time of steps 0–7
of simple PLC
0x0000–0XFFFF
0000
P10.35
ACC/DEC time of steps 8–15
of simple PLC
0x0000–0XFFFF
0000
P17.27
Simple PLC and actual step of
multi-step speed
0-15
0
5.5.15 Local encoder input
The VFD supports pulse count function by inputting the count pulse from HDI high-speed pulse port.
When the actual count value is no less than the set value, digital output terminal will output
count-value-reached pulse signal, and the corresponding count value will be zeroed out.
