IPE300 series engineering VFD Function parameter list
-194-
Function
code
Name
Description
Default
Modify
P17.14
Digital
adjustment value
Displays the adjustment on the VFD through
the UP/DOWN terminal.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.15
Torque reference
value
Relative to the percentage of the rated torque
of the present motor, displaying the torque
reference.
Range: -300.0%–300.0% (of the motor rated
current)
0.0%
●
P17.16
Linear speed
0–65535
0
●
P17.17
Reserved
0–65535
0
●
P17.18
Count value
0–65535
0
●
P17.19
AI1 input voltage
Displays the AI1 input signal.
Range: 0.00–10.00V
0.00V
●
P17.20
AI2 input voltage
Displays the AI2 input signal.
Range: -10.00V–10.00V
0.00V
●
P17.21
HDIA input
frequency
Display HDIA input frequency.
Range: 0.000–50.000kHz
0.000
kHz
●
P17.22
HDIB input
frequency
Display HDIB input frequency.
Range: 0.000–50.000kHz
0.000
kHz
●
P17.23
PID reference
value
Displays the PID reference value.
Range: -100.0–100.0%
0.0%
●
P17.24
PID feedback
value
Displays the PID feedback value.
Range: -100.0–100.0%
0.0%
●
P17.25
Motor power
factor
Displays the power factor of the current motor.
Range: -1.00–1.00
1.00
●
P17.26
Duration of this
run
Displays the duration of this run of the VFD.
Range: 0–65535min
0m
●
P17.27
Simple PLC and
actual step of
multi-step speed
Used to display simple PLC and actual step of
multi-step speed.
Range: 0–15
0
●
P17.28
Motor ASR
controller output
Output
Displays the ASR controller output value under
the vector control mode, relative to the
percentage of rated motor torque.
Range: -300.0%–300.0% (of the motor rated
current)
0.0%
●
P17.29
Pole angle of
open-loop SM
Displays the initial identification angle of SM.
Range: 0.0–360.0
0.0
●
