INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-195-
Function
code
Name
Description
Default
Modify
P17.30
Phase
compensation of
SM
Displays the phase compensation of SM.
Range: -180.0–180.0
0.0
●
P17.31
High-frequency
superimposed
current of SM
0.0%–200.0% (of the motor rated current)
0.0
●
P17.32
Motor flux
linkage
0.0%–200.0%
0.0%
●
P17.33
Exciting current
reference
Displays the exciting current reference value
under the vector control mode.
Range: -3000.0–3000.0A
0.0A
●
P17.34
Torque current
reference
Displays the torque current reference value
under the vector control mode.
Range: -3000.0–3000.0A
0.0A
●
P17.35
AC incoming
current
Displays the valid value of incoming current on
AC side.
Range: 0.0–5000.0A
0.0A
●
P17.36
Output torque
Displays the output torque value. During
forward running, the positive value is the
motoring state while the negative value is
generating state. During reverse running, the
positive value is the generating state while the
negative value is the motoring state.
Range: -3000.0Nm–3000.0Nm
0.0Nm
●
P17.37
Motor overload
count value
0–65535
0
●
P17.38
Process PID
output
-100.0%–100.0%
0.00%
●
P17.39
Parameter
download error
0.00–99.00
0.00
●
P17.40
Motor control
mode
Ones place: Control mode
0: Vector 0
1: Vector 1
2: Space voltage vector control
3: Closed-loop vector control
Tens place: Control status
0: Speed control
1: Torque control
2
●
