IPE300 series engineering VFD Function parameter list
-193-
Displays the valid value of current output
current of the VFD.
Range: 0.0–5000.0A
Displays the current motor speed.
Range: 0–65535RPM
Displays the present torque current of the VFD.
Range: -3000.0–3000.0A
Displays the present exciting current of the
VFD.
Range: -3000.0–3000.0A
Displays the present motor power; 100%
relative to the rated motor power. The positive
value is the motoring state while the negative
value is the generating state.
Range: -300.0–300.0% (relative to the rated
motor power)
Displays the present output torque of the VFD;
100% relative to the rated motor torque. During
forward running, the positive value is the
motoring state while the negative value is
generating state. During reverse running, the
positive value is the generating state while the
negative value is the motoring state.
Range: -250.0–250.0%
Estimated motor
frequency
Displays the estimated motor rotor frequency
under the open-loop vector condition.
Range: 0.00–P00.03
Displays the present DC bus voltage of the
VFD.
Range: 0.0–2000.0 V
Digital input
terminal status
Displays the present digital input terminal state
of the VFD.
0000–03F
Corresponds to HDIB, HDIA, S4, S3, S2 and
S1 respectively.
Digital output
terminal status
Displays the present digital output terminal
state of the VFD.
0000–000F
Corresponds to R02, RO1, HDO and Y1
respectively
