INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-188-
Function
code
Name
Description
Default
Modify
-50.0% – 50.0%)
27: Reduction rate of drop control (*100, Hz,
0.00 – 50.00Hz)
28: Number of slaves (0–15,
29–47: Reserved
P15.13
Sent PZD2
P91.22–P91.43 calibration value
0: Disable
1: Running frequency (x100, Hz, number
without sign)
2: Set frequency (x100, Hz)
3: Bus voltage (x10, V)
4: Output voltage (×1, V)
5: Output current (x10, A)
6: Output torque (x10, Nm, number with sign)
7: Output power (x10, kW, number with sign)
8: Rotation speed of running (x1, RPM,
number without sign)
9: Linear speed of running (x1, m/s)
10: Ramp reference frequency
11: Fault code
12: AI1 input (x100, V)
13: AI2 input (x100, V)
14: AI3 input (x100, V)
15: HDIA frequency value (x100, kHz)
16: Terminal input status
17: Terminal output status
18: PID reference (x100, %)
19: PID feedback (x100, %)
20: Motor rated torque (x10, Nm)
21: High-order bit of position reference
(signed)
22: Low-order bit of position reference
(unsigned)
23: High-order bit of position feedback
(signed)
24: Low-order bit of position feedback
(unsigned)
25: Status word 1
26: HDIB frequency value (x100, kHz)
0
○
P15.14
Sent PZD3
0
○
P15.15
Sent PZD4
0
○
P15.16
Sent PZD5
0
○
P15.17
Sent PZD6
0
○
P15.18
Sent PZD7
0
○
P15.19
Sent PZD8
0
○
P15.20
Sent PZD9
0
○
P15.21
Sent PZD10
0
○
P15.22
Sent PZD11
0
○
P15.23
Sent PZD12
0
○
