INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-122-
Function
code
Name
Description
Default
Modify
P02.14
Magnetic
saturation
coefficient 4 of
iron core of AM 1
0.0–100.0%
40.0%
○
P02.15
Rated power of
SM 1
0.1–3000.0kW
Model
depended
◎
P02.16
Rated frequency
of SM 1
0.01Hz–P00.03 (Max. frequency)
50.00Hz
◎
P02.17
Number of pole
pairs of SM 1
1–128
2
◎
P02.18
Rated voltage of
SM 1
0–1200V
Model
depended
◎
P02.19
Rated current of
SM 1
0.8–6000.0A
Model
depended
◎
P02.20
Stator resistance
of SM 1
0.001–65.535Ω
Model
depended
○
P02.21
Direct-axis
inductance of SM
1
0.01–655.35Mh
Model
depended
○
P02.22
Quadrature-axis
inductance of SM
1
0.01–655.35Mh
Model
depended
○
P02.23
Counter-emf of
SM 1
0–10000
300
○
P02.24
Reserved
0x0000–0xFFFF
0
●
P02.25
Reserved
0%–50.0% (of the motor rated current)
10%
●
P02.26
Overload
protection of
motor 1
0: No protection
1: Common motor protection (with low-speed
compensation). As the cooling effect of a
common motor is degraded at low speed
running, the corresponding electronic
thermal protection value needs to be
adjusted properly, the low compensation
indicates lowering the overload protection
threshold of the motor whose running
frequency is lower than 30Hz.
2: Variable-frequency motor protection
2
◎
