IPE300 series engineering VFD Function parameter list
-136-
Function
code
Name
Description
Default
Modify
Setting range: -100.0%–+100.0% (of the motor
rated current)
P04.36
Frequency
threshold for
pull-in current
switching in SM
V/F control
When the SM V/F control mode is enabled, the
function code is used to set the frequency
threshold for the switching between pull-in
current 1 and pull-in current 2.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
50.00H
z
○
P04.37
Reactive current
closed-loop
proportional
coefficient in SM
V/F control
When the SM V/F control mode is enabled, the
function code is used to set the proportional
coefficient of reactive current closed-loop control.
Setting range: 0–3000
50
○
P04.38
Reactive current
closed-loop
integral time in
SM V/F control
When the SM V/F control mode is enabled, the
function code is used to set the integral
coefficient of reactive current closed-loop control.
Setting range: 0–3000
30
○
P04.39
Reactive current
closed-loop
output limit in SM
VF control
When the SM V/F control mode is enabled, the
function code is used to set the output limit of the
reactive current closed-loop control. A greater
value indicates a higher reactive closed-loop
compensation voltage and higher output power
of the motor. In general, you do not need to
modify the function code.
Setting range: 0–16000
8000
○
P04.40
Enabling IF
mode for AM 1
0: Disable
1: Enable
0
◎
P04.41
Current setting in
IF mode for AM 1
When IF control is adopted for AM 1, the function
code is used to set the output current. The value
is a percentage in relative to the rated current of
the motor.
Setting range: 0.0–200.0%
120.0%
○
P04.42
Proportional
coefficient in IF
mode for AM 1
When IF control is adopted for AM 1, the function
code is used to set the proportional coefficient of
the output current closed-loop control.
Setting range: 0–5000
350
○
P04.43
Integral
coefficient in IF
When IF control is adopted for AM 1, the function
code is used to set the integral coefficient of the
150
○
