INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-137-
Function
code
Name
Description
Default
Modify
mode for AM 1
output current closed-loop control.
Setting range: 0–5000
P04.44
Frequency
threshold for
switching off IF
mode for AM 1
When IF control is adopted for AM 1, the function
code is used to set the frequency threshold for
switching off the output current closed-loop
control. When the frequency is lower than the
value of the function code, the current
closed-loop control in the IF control mode is
enabled;
and when the frequency is higher than that, the
current closed-loop control in the IF control mode
is disabled.
Setting range: 0.00–20.00 Hz
10.00H
z
○
P04.45
Enabling IF
mode for AM 2
0: Disable
1: Enable
0
◎
P04.46
Current setting in
IF mode for AM 2
When IF control is adopted for AM 2, the function
code is used to set the output current. The value
is a percentage in relative to the rated current of
the motor.
Setting range: 0.0–200.0%
120.0%
○
P04.47
Proportional
coefficient in IF
mode for AM 2
When IF control is adopted for AM 2, the function
code is used to set the proportional coefficient of
output current closed-loop control.
Setting range: 0–5000
350
○
P04.48
Integral
coefficient in IF
mode for AM 2
When IF control is adopted for AM 2, the function
code is used to set the integral coefficient of
output current closed-loop control.
Setting range: 0–5000
150
○
P04.49
Frequency
threshold for
switching off IF
mode for AM 2
When IF control is adopted for AM 2, the function
code is used to set the frequency threshold for
switching off the output current closed-loop
control. When the frequency is lower than the
value of the function code, the current
closed-loop control in the IF control mode is
enabled;
and when the frequency is higher than that, the
current closed-loop control in the IF control mode
is disabled.
Setting range: 0.00–20.00 Hz
10.00H
z
○
