INVT IPE300 Series - Page 189

IPE300 series engineering VFD Function parameter list
-178-
Function
code
Name
Description
Default
Modify
coefficient of
voltage regulator
during
undervoltage
stall
coefficient of the bus voltage regulator during
undervoltage stall.
Setting range: 0–1000
P11.19
Proportional
coefficient of
current regulator
during
undervoltage
stall
This parameter is used to set the
proportional coefficient of the active current
regulator during undervoltage stall.
Setting range: 0–1000
25
○
P11.20
Integral
coefficient of
current regulator
during
undervoltage
stall
This parameter is used to set the integral
coefficient of the active current regulator
during undervoltage stall.
Setting range: 0–2000
150
○
P11.21
Proportional
coefficient of
voltage regulator
during
overvoltage stall
This parameter is used to set the
proportional coefficient of the bus voltage
regulator during overvoltage stall.
Setting range: 0–1000
60
○
P11.22
Integral
coefficient of
voltage regulator
during
overvoltage stall
This parameter is used to set the integral
coefficient of the bus voltage regulator during
overvoltage stall.
Setting range: 0–1000
10
○
P11.23
Proportional
coefficient of
current regulator
during
overvoltage stall
This parameter is used to set the
proportional coefficient of the active current
regulator during overvoltage stall.
Setting range: 0–1000
60
○
P11.24
Integral
coefficient of
current regulator
during
overvoltage stall
This parameter is used to set the integral
coefficient of the active current regulator
during overvoltage stall.
Setting range: 0–2000
250
○
