INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-191-
Function
code
Name
Description
Default
Modify
P15.37
State
change/cycle
output instance
19: INVT VFD output
20: ODVA basic speed control output
21: ODVA extended speed control output
22: ODVA speed and torque control output
23: ODVA extended speed and torque
control output
24: INVT basic speed control output
25: INVT extended speed control output
26: INVT speed and torque control output
27: INVT extended speed and torque control
output
19
○
P15.38
State
change/cycle
input instance
69: INVT VFD input
70: ODVA basic speed control input
71: ODVA extended speed control input
72: ODVA speed and torque control input
73: ODVA extended speed and torque
control input
74: INVT basic speed control input
75: INVT extended speed control input
76: INVT speed and torque control input
77: INVT extended speed and torque control
input
69
○
P15.39
Component 19
output length
8–32
32
○
P15.40
Component 19
input length
8–32
32
○
P15.41
BACnet
communication
mode
0: P16.22 is enabled.
1: P15.42 is enabled.
0
◎
P15.42
Baud rate of
BACnet_MSTP
0–5
0
◎
P15.43
ID of DP device
0x0000–0xFFFF
0
◎
P15.44
DP
communication
protocol
resolution
0: Define CW and SW freely by bit
1: CW and SW fixed (original GD series
mode)
0
◎
P15.45–
P15.69
Reserved
0–65535
0
●
