INVT IPE300 Series User Manual

IPE300 series engineering VFD Product overview
-11-
Description
Specifications
Automatic voltage
regulation
The output voltage can be kept constant although the grid
voltage changes.
Fault protection
More than 30 protection functions, such as protection
against overcurrent, overvoltage, undervoltage,
overtemperature, phase loss, and overload
Speed tracking
restart
Used to implement impact-free smooth startup for rotating
motors
Note: The function is available only for the 0004 and higher
VFD models.
Peripheral
interface
Terminal analog
input resolution
No more than 20mV
Terminal digital input
resolution
No more than 2ms
Analog input
2 inputs; AI1: 0–10V/0–20mA; AI2: -10–10V
Analog output
1 input; AO1: 0–10V/0–20mA
Digital input
Four regular inputs; max. frequency: 1kHz; internal
impedance: 3.3kΩ
Two high-speed inputs; max. frequency: 50kHz; supporting
quadrature encoder input; with speed measurement function
Digital output
One high-speed pulse output; max. frequency: 50kHz
One Y terminal open collector output
Relay output
Two programmable relay outputs
RO1A: NO; RO1B: NC; RO1C: common
RO2A: NO; RO2B: NC; RO2C: common
Contact capacity: 3A/AC250V, 1A/DC30V
Extended interfaces
Three extended interfaces: SLOT1, SLOT2, and SLOT3
Supporting PG cards, programmable extension cards,
communication cards, I/O cards and so on
Other
Installation method
Supports wall-mounting, floor-mounting and
flange-mounting.
Temperature of
running environment
-10°C – +50°C; Derating is required if the ambient
temperature exceeds 40°C.
IP rating
IP20
Pollution level
Level 2
Cooling method
Forced air cooling
Braking unit
The braking unit has been built in the 380V 0037 and lower
VFD models.
It is optional for the 380V 0045–0110 (inclusive) models and
can be built in the VFD.
It is optional for the 660V models and can be externally
connected to the VFD.
