INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-213-
Function
code
Name
Description
Default
value
Modify
Bit6: Zeroing command selection
0: Electric level mode
1: Pulse mode
Bit7: Reference point calibration mode
0: Calibrate at the first time
1: Calibrate in real time
Bit8: Action selection after zeroing signal
cancellation (electric level type)
0: Switch to speed mode
1: Position lock mode
Bit9: Positioning completion signal selection
0: Electric level signal
1: Pulse signal
Bit10: Z pulse signal source
0: Motor
1: Spindle
Bits 11–15: Reserved
P22.01
Speed of spindle
orientation
During spindle orientation, the speed of the
position point of orientation will be searched, and
then it will switch over to position control
orientation.
Setting range: 0.00–100.00Hz
10.00Hz
○
P22.02
Deceleration time
of spindle
orientation
Deceleration time of spindle orientation.
Spindle orientation deceleration time means the
time needed for the VFD to decelerate from Max.
output frequency (P00.03) to 0Hz.
Setting range: 0.0–100.0s
3.0s
○
P22.03
Spindle zeroing
position 0
You can select the zeroing positions of four
spindles by terminals (functions 46 and 47).
Setting range: 0–39999
0
○
P22.04
Spindle zeroing
position 1
Setting range: 0–39999
0
○
P22.05
Spindle zeroing
position 2
Setting range: 0–39999
0
○
P22.06
Spindle zeroing
position 3
Setting range: 0–39999
0
○
