INVT IPE300 Series User Manual

IPE300 series engineering VFD Troubleshooting
-254-
Fault
code
Fault
No.
Fault type
Possible cause
Solution
E-NET
30
Ethernet card
communication
timeout fault
There is no data transmission
between the communication
card and the host computer.
Check whether the
communication card wiring
is loose or dropped.
E-CAN
31
CANopen card
communication
timeout fault
There is no data transmission
between the communication
card and the host computer (or
PLC).
Check whether the
communication card wiring
is loose or dropped.
E-PN
57
PROFINET card
communication
timeout fault
There is no data transmission
between the communication
card and the host computer (or
PLC).
Check whether the
communication card wiring
is loose or dropped.
E-CAT
66
EtherCAT card
communication
timeout fault
There is no data transmission
between the communication
card and the host computer (or
PLC).
Check whether the
communication card wiring
is loose or dropped.
E-BAC
67
BACNet card
communication
timeout fault
There is no data transmission
between the communication
card and the host computer (or
PLC).
Check whether the
communication card wiring
is loose or dropped.
E-DEV
68
DeviceNet card
communication
timeout fault
There is no data transmission
between the communication
card and the host computer (or
PLC).
Check whether the
communication card wiring
is loose or dropped.
ESCAN
58
CAN master/slave
card communication
timeout fault
There is no data transmission
between the CAN master and
slave communication cards.
Check whether the
communication card wiring
is loose or dropped.
S-Err
69
Master/slave
synchronous CAN
slave fault
Fault occurred to one of the
CAN slave VFDs.
Detect the CAN slave VFD
and analyze the
corresponding fault cause of
the VFD.
OtE1
70
PT100
overtemperature
fault
Present ambient temperature
is too high;
PT100 detection wiring error;
PT100 overtemperature
protection setting is improper.
Check the present ambient
temperature;
Check the PT100 wiring;
Check whether the
over-temperature fault point
of PT100 is set too small.
