INVT IPE300 Series User Manual

IPE300 series engineering VFD Communication protocol
-285-
Function
Address
Data description
R/W
VFD status word 2
2101H
Bit0: =0: Not ready to run =1: Ready to run
Bit1–2=00: Motor 1 =01: Motor 2
Bit3: =0: AM =1: SM
Bit4: = 0: No pre-alarm upon overload =1:
overload pre-alarm
Bit5–Bit6=00: Keypad-based control
=01: Terminal-based control
=10: Communication-based control
Bit7: Reserved
Bit8=0: Speed control
=1: Torque control
Bit9=0: Non position control
=1: Position control
Bit10–11: =0: Vector 0 =1: Vector 1
=2: Closed-loop vector = 3: Space voltage vector
R
VFD fault code
2102H
See the description of fault types.
R
VFD identification
code
2103H
IPE300-----0x01A0
R
Running frequency
3000H
0–Fmax (Unit: 0.01Hz)
Compatible
with CHF100A
and CHV100
communication
addresses
R
Set frequency
3001H
0–Fmax (Unit: 0.01Hz)
R
Bus voltage
3002H
0.0–2000.0V (Unit: 0.1V)
R
Output voltage
3003H
0–1200V (Unit: 1V)
R
Output current
3004H
0.0–3000.0A (Unit: 0.1A)
R
Rotational speed
3005H
0–65535 (Unit: 1RPM)
R
Output power
3006H
-300.0–300.0% (Unit: 0.1%)
R
Output torque
3007H
-250.0–250.0% (Unit: 0.1%)
R
Closed-loop setting
3008H
-100.0–100.0% (Unit: 0.1%)
R
Closed-loop feedback
3009H
-100.0–100.0% (Unit: 0.1%)
R
Input I/O status
300AH
000–3F
Corresponding to the local HDIB/
HDIA/S4/S3/S2/S1
R
Output I/O status
300BH
000–0F
Corresponding to local
RO2/RO1/HDO/Y1
R
Analog input 1
300CH
0.00–10.00V (Unit: 0.01V)
R
Analog input 2
300DH
0.00–10.00V (Unit: 0.01V)
R
Analog input 3
300EH
-10.00–10.00V (Unit: 0.01V)
R
Analog input 4
300FH
R
