IPE300 series engineering VFD Extension card
-296-
Field
Description
Naming example
①
Product
category
EC extension card
②
Board card
category
PC: PLC programmable card
③
Technology
version
The odd numbers 1, 3, and 5 are used to represent the 1st,
2nd, and 3rd generations of the technology version.
④
Distinguishing
code
01: 10 points, with 6 inputs and 4 outputs (2 transistor
outputs + 2 relay outputs)
02: 8 points, IO+1AI+1AO+485 communication
03: Reserved
⑤
Special
requirement
Reserved
EC-TX 5 03
① ② ③ ④
Sign
Description
Naming example
①
Product
category
EC extension card
②
Board card
category
TX: communication extension card
③
Technology
version
The odd numbers 1, 3, and 5 are used to represent the 1st,
2nd, and 3rd generations of the technology version.
④
Distinguishing
code
01: Bluetooth communication card
02: WIFI
03: PROFIBUS communication card
05: CANopen communication card
06: DeviceNet communication card
07: BACnet communication card
08: EtherCAT communication card
09: PROFINET communication card
10: Ethernet/IP communication card
11: CAN master/slave control communication card
