IPE300 series engineering VFD Extension card
-302-
The following figure shows the installation diagram and the VFD with extension cards installed.
EC 3
EC 2
EC 1
EC installation diagram
Diagram of ECs installed
EC 1
EC 3
EC 2
Figure A-1 7.5kW or higher VFD models with extension cards installed
EC 1
EC 2
ECs installing
ECs installed
EC 1
EC 2
Figure A-2 5.5kW or lower VFD models with extension cards installed
