INVT IPE300 Series User Manual

IPE300 series engineering VFD Optional peripheral accessories
-356-
 According to the working principle and structure of breakers, if the manufacturer's
regulation is not followed, hot ionized gases may escape from the breaker
enclosure when a short-circuit occurs. To ensure safe use, exercise extra caution
when installing and placing the breaker. Follow the manufacturer's instructions.
To ensure safety, you can configure an electromagnetic contactor on the input side to control the
switch-on and switch-off of the main circuit power, so that the input power supply of the VFD can be
effectively cut off when a system fault occurs.
Table D-3 AC 3PH 380V (-15%)–440V (+10%)
VFD model
Breaker rated
current (A)
High speed fuse
(A)
Contactor rated current
(A)
IPE300-01R5-4
6/10
10/10
9/9
IPE300-02R2-4
10/20
10/20
9/18
IPE300-0004-4
20/25
20/35
18/25
IPE300-05R5-4
25/32
35/40
25/32
IPE300-07R5-4
32/50
40/50
32/38
IPE300-0011-4
50/63
50/60
38/50
IPE300-0015-4
63/63
60/70
50/65
IPE300-0018-4
63/80
70/90
65/80
IPE300-0022-4
80/100
90/125
80/80
IPE300-0030-4
100/125
125/125
80/98
IPE300-0037-4
125/140
125/150
98/115
IPE300-0045-4
140/180
150/200
115/150
IPE300-0055-4
180/225
200/250
150/185
IPE300-0075-4
225/250
250/300
185/225
IPE300-0090-4
250/315
300/350
225/265
IPE300-0110-4
315/400
350/400
265/330
IPE300-0132-4
400/500
400/500
330/400
IPE300-0160-4
500/500
500/600
400/400
IPE300-0185-4
500/630
600/600
400/500
IPE300-0200-4
630/630
600/700
500/500
IPE300-0220-4
630/700
700/800
500/630
IPE300-0250-4
700/800
800/1000
630/630
IPE300-0280-4
800/1000
1000/1000
630/800
IPE300-0315-4
1000/1000
1000/1000
800/800
IPE300-0355-4
1000/1000
1000/1200
800/1000
IPE300-0400-4
1000/1250
1200/1200
1000/1000
IPE300-0450-4
1250/1250
1200/1400
1000/1000
IPE300-0500-4
1250
1400
1000
