INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-46-
Function
code
Name
Description
Default
3: AI2
4: AI3
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus communication
8: PROFIBUS/CANopen/DeviceNet communication
9: Ethernet communication
10: Pulse frequency HDIB
11: EtherCAT/PROFINET communication
12: PLC
Note: For setting sources 2–6 and 10, 100%
corresponds to three times the rated motor current.
P03.12
Torque set
through keypad
-300.0%–300.0% (of the motor rated current)
50.0%
P03.13
Torque reference
filter time
0.000–10.000s
0.010s
P03.14
Torque control
Setting source of
forward rotation
upper-limit
frequency in
torque control
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus communication
7: Profibus/CANopen/DeviceNet communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCat/Profinet communication
11: PLC
12: Reserved
Note: For setting methods 1–11, 100% corresponds to
the maximum frequency.
0
P03.15
Setting source of
reverse rotation
upper-limit
frequency in
torque control
0: Keypad (P03.17)
1–11: Same as those for P03.14
0
P03.16
Forward rotation
upper-limit
Setting range: 0.00 Hz–P00.03 (Max. output frequency)
50.00Hz
