IPE300 series engineering VFD Function parameter list
-126-
Function
code
Name
Description
Default
Modify
Note: For setting sources 2–6 and 10, 100%
corresponds to three times the rated motor
current.
P03.12
Torque set
through keypad
-300.0%–300.0% (of the motor rated current)
20.0%
○
P03.13
Torque reference
filter time
0.000–10.000s
0.010s
○
P03.14
Setting source of
forward rotation
upper-limit
frequency in
torque control
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus communication
7: Profibus/CANopen/DeviceNet
communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCat/Profinet communication
11: PLC
12: Reserved
Note: For setting methods 1–11, 100%
corresponds to the maximum frequency.
0
○
P03.15
Setting source of
reverse rotation
upper-limit
frequency in
torque control
0: Keypad (P03.17)
1–11: the same as P03.14
0
○
P03.16
Forward rotation
upper-limit
frequency set
through keypad
in torque control
Used to set the frequency upper limits. 100%
corresponds to the max. frequency. P03.16 sets
the value when P03.14=1; P03.17 sets the value
when P03.15=1.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
50.00H
z
○
P03.17
Reverse rotation
upper-limit
frequency set
through keypad
in torque control
50.00H
z
○
