IPE300 series engineering VFD Basic operation guidelines
-45-
Function
code
Name
Description
Default
P02.00
Type of motor 1
0: Asynchronous motor (AM)
1: Synchronous motor (SM)
0
P03.00
Speed-loop
proportional gain
1
0–200.0
20.0
P03.01
Speed-loop
integral time 1
0.000–10.000s
0.200s
P03.02
Low-point
frequency for
switching
0.00Hz–P03.05
5.00Hz
P03.03
Speed-loop
proportional gain
2
0–200.0
20.0
P03.04
Speed-loop
integral time 2
0.000–10.000s
0.200s
P03.05
High-point
frequency for
switching
P03.02–P00.03 (Max. output frequency)
10.00Hz
P03.06
Speed-loop
output filter
0–8 (0–2
8
/10ms)
0
P03.07
Electromotive
slip
compensation
coefficient of
vector control
50%–200.0%
100%
P03.08
Braking slip
compensation
coefficient of
vector control
50%–200.0%
100%
P03.09
Current-loop
proportional
coefficient P
0–65535
1000
P03.10
Current-loop
integral
coefficient I
0–65535
1000
P03.11
Torque setting
method
1: Keypad (P03.12)
2: AI1
1
