INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-86-
Setting
Function
Description
57
Motor overtemperature
fault input
When there is motor overtemperature fault input, the motor
stops due to the fault.
59
Switch from VC to space
voltage vector control
When the function is enabled in stopped state, space voltage
vector control is used.
60
Switch to VC control
When the function is enabled in stopped state, VC is used.
61
Switch PID polarities
Used to switch the output polarity of PID. It is used together
with P09.03.
62
Reserved
63
Enabling servo
When the thousands place of P21.00 enables servo, the servo
enabling terminal is valid, which controls the VFD to enter zero
servo control. At this time, the start command is not needed.
64
Limit on forward running
Limit on forward running.
65
Limit on reverse running
Limit on reverse running.
66
Clear encoder counting
Used to clear the position counting value.
67
Increase pulses
When the terminal function is valid, the pulse input is
increased according to the P21.27 pulse speed.
68
Enable pulse
superposition
Pulse increment and pulse decrement can be valid only after
pulse superimposition is enabled.
69
Decrease pulses
When the terminal function is valid, the pulse input is
decreased according to the P21.27 pulse speed.
70
Electronic gear selection
When the terminal is valid, the proportional numerator is
switched to the P21.30 numerator of the 2nd command ratio.
71
Switch to the master
In master-slave control mode, when the terminal is valid, the
current VFD is switched from the slave mode to the master
mode.
72
Switch to the slave
In master-slave control mode, when the terminal is valid, the
current VFD is switched from the master mode to the slave
mode.
73
Enable RO output 1
When the terminal is valid and a relay terminal function is set
to “54: S terminal input 1 is valid”, the relay outputs actions.
74
Enable RO output 2
When the terminal is valid and a relay terminal function is set
to “55: S terminal input 1 is valid”, the relay outputs actions.
75
Brake release command
input
When the terminal is active in the brake control mode, the
release command is output.
76
Brake feedback signal
When the terminal is active in the brake control mode, the
brake feedback signal is received.
77–79
Reserved
