INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-85-
Setting
Function
Description
37
Switch the running
command channel to
terminal
When the function is enabled, the running command channel
is switched to terminal. When the function is disabled, the
running command channel is restored to the previous setting.
38
Switch the running
command channel to
communication
When the function is enabled, the running command channel
is switched to communication. When the function is disabled,
the running command channel is restored to the previous
setting.
39
Pre-exciting command
When the function is enabled, motor pre-exciting is started
until the function becomes invalid.
40
Clear power
consumption quantity
After this command becomes valid, the power consumption
quantity of the VFD will be zeroed out.
41
Keep power
consumption quantity
When the function is enabled, the present operation of the
VFD does not impact the power consumption quantity.
42
Switch the setting
source of braking torque
upper limit to keypad
The torque upper limit is set through the keypad when the
command is valid.
43
Position reference point
input
Only valid for S1, S2, S3
46
Spindle zeroing position
selection 1
Spindle zeroing position 1 selected through terminal
47
Spindle zeroing position
selection 2
Spindle zeroing position 2 selected through terminal
48
Spindle scale division
selection 1
Spindle scale division value 1 selected through terminal
49
Spindle scale division
selection 2
Spindle scale division value 2 selected through terminal
50
Spindle scale division
selection 3
Spindle scale division value 3 selected through terminal
51
Terminal for switching
between position control
and speed control
Switch between position control and speed control
52
Disable pulse input
When the terminal is active, the pulse input is invalid
53
Clear position deviation
Clear the input deviation of the position loop
54
Switch position
proportional gains
Switch the position proportional gains
55
Enable cyclic digital
positioning
Enabling cyclic positioning function in digital position
positioning mode
56
Emergency stop
When the function is enabled, the motor decelerates to stop in
emergency manner according to the time specified by P01.25.
