INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-84-
Setting
Function
Description
21
ACC/DEC time selection
1
The status of the two terminals can be combined to select four
groups of ACC/DEC time.
Terminal 1
Terminal 2
ACC/DEC time
Parameter
OFF
OFF
ACC/DEC time 1
P00.11/P00.12
ON
OFF
ACC/DEC time 2
P08.00/P08.01
OFF
ON
ACC/DEC time 3
P08.02/P08.03
ON
ON
ACC/DEC time 4
P08.04/P08.05
22
ACC/DEC time selection
2
23
Simple PLC stop reset
Used to clear the previous PLC state memory information and
restart the simple PLC process.
24
Pause simple PLC
Used to pause the simple PLC. When the function is revoked,
the simple PLC resumes the running.
25
Pause PID control
PID is ineffective temporarily, and the VFD maintains current
frequency output.
26
Pause wobbling
frequency (stop at
current frequency)
The VFD pauses at current output. After this function is
canceled, it continues wobbling-frequency operation at current
frequency.
27
Reset wobbling
frequency (back to
center frequency)
The set frequency of VFD reverts to center frequency.
28
Reset the counter
The counter is cleared.
29
Switch between speed
control and torque
control
The VFD switches from torque control mode to speed control
mode, or vice versa.
30
Disable ACC/DEC
Used to ensure the VFD is not impacted by external signals
(except for stop command), and maintains the present output
frequency.
31
Trigger the counter
Used to enable the counter to count pulses.
33
Clear the frequency
increase/decrease
setting temporarily
When the terminal is closed, the frequency value set by
UP/DOWN can be cleared to restore the reference frequency
to the frequency given by frequency command channel; when
the terminal is opened, it restores to the frequency value after
frequency increase/decrease setting.
34
DC braking
The VFD starts DC brake immediately after the command
becomes valid.
35
Switch between motor 1
and motor 2
When the function is enabled, you can realize switchover
control of two motors.
36
Switch the running
command channel to
keypad
When the function is enabled, the running command channel
is switched to keypad. When the function is disabled, the
running command channel is restored to the previous setting.
