IPE300 series engineering VFD Function parameter list
-113-
Function
code
Name
Description
Default
Modify
P00.10
Frequency set
through keypad
When A and B frequency commands select the
keypad for setting, the value of the function
code is the original setting one of the frequency
data of the VFD.
Setting range: 0.00 Hz–P00.03 (Max. output
frequency)
50.00Hz
○
P00.11
ACC time 1
ACC time means the time needed if the VFD
speeds up from 0Hz to the max. output
frequency (P00.03).
DEC time means the time needed if the VFD
speeds down from the max. output frequency
(P00.03) to 0Hz.
The inverter unit has four groups of ACC/DEC
time, which can be selected by P05. The
default ACC/DEC time of the inverter unit is the
first group. The factory default ACC/DEC time
of the VFD is the first group.
P00.11 and P00.12 setting range: 0.0–3600.0s
Model
depended
○
P00.12
DEC time 1
Model
depended
○
P00.13
Running direction
0: Run at the default direction.
1: Run at the opposite direction.
2: Disable reverse running
0
○
P00.14
Carrier frequency
Carrier
frequency
Electro magnetic
noise
Noise and leakage
current
Cooling
level
High
LowHigh
Low
High
Low
1kHz
10kHz
15kHz
The relationship between models and carrier
frequencies is as follows:
Model
Default carrier
frequency
380V
1.5–11kW
8kHz
15–55kW
4kHz
>75kW
2kHz
660V
22–55kW
4kHz
>75kW
2kHz
Model
depended
○
