0x00–0x11
Ones place: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens place: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0: No function
1: Run forward
2: Run reversely
3: Three-wire running control
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
9: External fault input
10: Increase frequency setting (UP)
11: Decrease frequency setting (DOWN)
12: Clear the frequency increase/decrease
setting
13: Switch between A setting and B setting
14: Switch between combination setting and A
setting
15: Switch between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Pause multi-step speed running
21: ACC/DEC time selection 1
22: ACC/DEC time selection 2
23: Simple PLC stop reset
24: Pause simple PLC
25: Pause PID control
