iPECS UCM - Page 69

iPECS UCM
Installation Manual Issue 1.1
62
Champ connector wiring (CO/LD)
Port No. Signal Name Pin No. Signal Name
1 TIP0 1 33 RING0
2
TIP1
2
34
RING1
3 TIP2 3 35 RING2
4 TIP3 4 36 RING3
5 TIP4 5 37 RING4
6 TIP5 6 38 RING5
7 TIP6 7 39 RING6
8
TIP7
8
40
RING7
9 TIP8 9 41 RING8
10 TIP9 10 42 RING9
11
TIP10
11
43
RING10
12 TIP11 12 44 RING11
13 TIP12 13 45 RING12
14 TIP13 14 46 RING13
15 TIP14 15 47 RING14
16 TIP15 16 48 RING15
17
-
17
49
-
18 - 18 50 -
19 - 19 51 -
20
-
20
52
-
21 - 21 53 -
22 - 22 54 -
23 - 23 55 -
24 - 24 56 -
25 - 25 57 -
26
-
26
58
-
27 - 27 59 -
28 - 28 60 -
29
-
29
61
-
30 - 30 62 -
31 - 31 63 -
32 - 32 64 -
