3.2 Mx-SENS2 8
Fast 8-Channel Analog Measurement
Device with Excitation
8 analog signal inputs for voltage /
current
8 separate sensor excitations,
supply voltage individually selectable
(up to ±15 V, ±45 mA)
12 unipolar and 12 bipolar
measuring ranges
2 current measuring ranges
10 mV range, e.g. for stanby current
applications
Offset and target value adjust functions
Status LED at each input channel
(channel identification / channel error idication)
Measurement data output to Ethernet using XCPonEthernet,
Measurement data output to CAN
Complete galvanic isolation (inputs, excitation, CAN, Ethernet, power supply, enclosure)
Designed for automotive use
Toolless module to module connection
