4.6 M-SENS2
4-Channel Analog Input with Sensor Excitation
4 measurement inputs for voltage / current
4 separate sensor excitations, supply voltage
individually selectable (up to 15 V, 60 mA)
12 unipolar and 12 bipolar measuring ranges
TEDS support (optional)
Measurement data output to CAN
Complete galvanic isolation (signal inputs,
excitation, CAN, power supply, enclosure)
Designed for engine compartment applications
Toolless module to module connection
4.6.1 Input cables
Standard (open)
670-807.xxx SIM-SENS Kabel offen (M-SENS, M-SENS2)
