The offset adjustment is supported by the respective device from the following firmware version:
M-SENS, M-SENS 8 >= V3.12.07
M-SENS 8plus >= V3.12.08
The calibration function with a broadcast command (IPEhotkey) also allows the offset adjustment during a
running acquisition to a user defined target value (reference value). The following actions are permitted:
None no offset calibration
Manually only channels with this status are calibrated with the Manual calibration
command
Group X channels, which are assigned to a specific group (1…4), are calibrated
with the desktop icon IPEhotkey and the Calibration Group command.
The channel assignation to one group can also be effected for all devices (e.g.
SENS type, STG, CANpressure mixed in one group). A signal-based calibration
is therefore possible.
5.4.9 M-CNT2
Format (M-CNT2)
M-CNT2 provides extended input settings in the Format tab (data type).
In addition to data types 8 Bit and 16 Bit integer signed/unsigned type 32 Bit integer signed/unsigned is
selectable in order to transfer numerical values > 65535 to the DAQ software (requestet for measurement
frequency > 65.5 kHz resp. counter reading > 65.5 k).
