Scaling, measuring ranges
Scaling M-FRQ Scaling M-CNT2
Scaling
1. Select the mode for frequency or period acquisition.
2. Select a sensor range. Depending on the device/channel,
different ranges are available.
3. Define a physical range and the unit with the scaling
calculator – if required.
