Iseki TM3265 - TABLE 2: Arrangement of gears...

OPERATION
43
TABLE 2: Arrangement of gears with appropriate ground
speeds, in order from slow to fast, are shown in chart
below, for mechanical transmission.
TABLE 2: Speed chart (Mechanical Transmission)
Shift
Positions
TM3215
(Engine 2500 min-1)
TM3245
(Engine 2600 min-1)
TM3265
(Engine 2600 min-1)
Range Gear Km / h Km / h Km / h
Tire
Agri
(9.5 - 16)
Turf
(31X13.5 - 15)
Agri
(9.5 - 18)
Turf
(315 / 75D - 15)
Agri
(95 - 16)
Turf
(315 / 75D - 15)
Forward
1 1.5 1.4 1.7 1.6 1.7 1.6
2 2.0 1.9 2.2 2.1 2.2 2.1
3 3.1 2.8 3.4 3.2 3.4 3.2
4 4.0 3.7 4.4 4.2 4.4 4.2
1 7.5 6.9 8.3 7.9 8.3 7.9
2 10.2 9.4 11.2 10.7 11.2 10.7
3 15.5 14.2 17.0 16.2 17.0 16.2
4 20.1 18.5 22.2 21.1 22.2 21.1
Max. Speed
(forward)
High Idle High Idle High Idle
22.1 20.4 24.4 23.2 24.4 23.2
Reverse
1 1.3 1.2 1.5 1.4 1.5 1.4
2 1.8 1.7 2.0 1.9 2.0 1.9
3 2.8 2.5 3.0 2.9 3.0 2.9
4 3.6 3.3 3.9 3.8 3.9 3.8
1 6.7 6.2 7.4 7.0 7.4 7.0
2 9.1 8.3 10.0 9.5 10.0 9.5
3 13.8 12.7 15.2 14.5 15.2 14.5
4 17.9 16.5 19.7 18.8 19.7 18.8
