TM3215, 3245, 3265
62
FALLING OBJECTS PROTECTIVE STRUCTURE
(FOPS) & OPERATORS PROTECTION STRUCTURE
(OPS) FIXATION POINT
Consult your ISEKI dealer concerning the fixation points
on tractor for the FOPS & OPS.
NOTE: FOPS and OPS are not standard equipment.
TOWING
Consult your ISEKI dealer for towing tractor as much as
possible. If such cases as listed below, call your ISEKI
dealer as transmission might be broken.
• Although the engine runs, tractor cannot start to move.
• Unusual noise occurs.
FIG. 110: Hook up the rope to the front hitch, 1. The dis-
tance between towing vehicle and tractor should be less
than 5 m.
Move the range gear shift lever to the neutral position.
Release the parking brake lock.
JACKING
When jacking tractor, place the tractor on level, hard
ground which is sufficiently illuminated, otherwise un-
expected accidents may occur. Follow the instructions
listed below:
• Apply parking brakes.
• Disengage all PTO.
• Place all gear shift levers in neutral.
• Remove the starter key.
• Place the jack on level.
• Put tire chocks to the rear wheels when jacking up the
front wheels.
• Put tire chocks to the front wheels when jacking up
the rear wheels.
FIG. 111: When raising the rear axle, suitable shims, 1,
should be wedged between the front axle and the front
frame.
FIGS. 110 & 112: When raising the front axle, the jack-
ing point is the front hitch, 1, or the front pivot, 2. For the
rear axle, the jacking point is the rear hitch, 3.
1
2
FIG. 110
1
FIG. 111
3
FIG. 112
