ISHIDA Uni-3 Service Manual

Chapter 1 BASIC INFORMATION
UNI-3 Service Manual 1-5
1.2 SPECIFICATIONS
Items
Descriptions
Use conditions Temperature: -5 to 40°C
Humidity: 30 to 85%, Non condensing.
Power supply /
Power consumption
For EU: AC220 – 240V / 0.5A
For South Africa: AC220 – 240V / 0.5A
For USA: AC100 – 120V / 1.0A
For Argentina: AC220 – 240V / 0.5A
Weighing capacity
Scale interval
15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg, 30kg: 0.01kg
30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb, 60lb: 0.02lb
Weighting accuracy
1/3000
Operator/Customer display L1:One line
16 segments x 23 digits, liquid crystal with backlight
L2:Two lines
<upper>192 x 16 dots
<lower>7 segments x 23 digits, liquid crystal with backlight
Printing method
Direct thermal method
Thermal head
2 inches (448dots) and 8 dots/mm
Printing speed 100mm/second
Note: The printing speed may vary according to label conditions.
Printing effective size
56mm
Label size Label width: 38mm to 64mm
Label length: 30mm to 175mm
Number of label cassettes
non cassette
Input/Output LAN 1 channel
USB 1 channel
Drawer 1 channel
Program store medium
Flash ROM (32M bytes)
