ISHIDA Uni-3 Service Manual

Chapter 4 ELECTRICAL SIGNALS
UNI-3 Service Manual 4-1
ELECTRICAL SIGNALS
4.1 MAIN BOARD
XJ1
No. Signal Name Direction Opposite Side
1 TX+ <-->
LAN
2 TX- <-->
3 RX+ <-->
4 Not connected
5 Not connected
6 RX- <-->
7 Not connected
8 Not connected
XJ2
No. Signal Name Direction Opposite Side
1 Unused
Cash drawer
2 DC+24V for drawer -
3 GND for drawer -
4 Unused
XJ5
No. Signal Name Direction Opposite Side
1 DC+5V -
Wireless LAN
2 GND -
4
