ISHIDA Uni-3 Service Manual

Chapter 6 SETUP MODE
6-100 UNI-3 Service Manual
04-SCALE INIT
The dot display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
<
S
C
A
L
E
I
N
I
T
.
>
[
E
N
T
]
The segment display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
B
2
7
-
0
4
<
S
C
A
L
E
I
N
I
T
.
>
Dot display
Segment display
Setting value
*USB-TO-SCALE [ENT]
B27-01 USB-TO-SCALE
*INPUT SELECT [PLU] B27-01-01 I/P SELECT >P< Start reading information using
[PLU] button.
*SEL USB FOLDER B27-100 SEL USB FOLDER Select folder to read out.
Select using "“" key.
Maximum of 7 folders from
USB01 to USB07
*USB DATA 01 [PLU] B27-101 USB DATA 01 >P< Selection status of USB01 If the
folder name is registered, the
folder name will be displayed.
Press the [PLU] button to make
selection.
*MASTER MODE 2:MANUAL
B27-01-03 MASRTER MODE 2
1: AUTO 2: MANUAL
*EXECUTE [ZERO]
B27-01-04 EXECUTE >2<
Execute using [PLU] button
INPUT CHECK 14011-0000 EXEC OR STOP Execute confirmation screen
Start restore using [PLU] button
When COMPLETE INPUT is
displayed, restore is finished.
<SCALE-TO-USB> [ENT]
B27-02 <SCALE-TO-USB>
*OUTPUT SELECT [PLU] B27-02-01 O/P SELECT >P< Start reading information using
[PLU] button.
*SEL USB FOLDER B27-200 SEL USB FOLDER Select folder to record.
Select using "“" key.
Maximum of 7 folders from
USB01 to USB07
*USB DATA 01 [PLU] B27-201 USB DATA 01 >P< Selection status of USB01 If the
folder name is registered, the
folder name will be displayed.
Press the [PLU] button to make
