ISHIDA Uni-3 Service Manual

Chapter 4 ELECTRICAL SIGNALS
UNI-3 Service Manual 4-7
4.6 WIRELESS LAN BOARD (PK-265)
XJ1
No. Signal Name Direction Opposite Side
1 DC+5V -
Main board PS-990* XJ5
2 GND -
XJ2
No. Signal Name Direction Opposite Side
1 TX+ ->
Main board PS-990* XJ1
2 TX- ->
3 RX+ <-
6 RX- <-
10 LEDR -
11 LEDL -
4,7,13,14 GND -
9,12 DC+3.3V -
