ISHIDA Uni-3 Service Manual

Chapter 7 ADJUSTMENT MODE
7-20 UNI-3 Service Manual
C07-01 HEAD
The dot display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
<
H
E
A
D
>
The segment display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
C
0
7
-
0
1
<
H
E
A
D
>
The THERMAL HEAD adjustment item
1: Test printing (Checker board pattern/Regular print)
2: Type of head (BHE4256 fixed)
3: Running distance
4: Resistance value (Thermal head)
5: Backward feeding adjustment (45mm)
6: Backward feeding adjustment (60mm)
7: Backward feeding adjustment (80mm)
8: Malfunction check of heater (YES/NO)
Executes the initialization process.
The initialization of the printer settings: Press the [TARE] key.
The initialization of the thermal head: Press the [ZERO] key.
