ISHIDA Uni-3 Service Manual

Chapter 7 ADJUSTMENT MODE
7-54 UNI-3 Service Manual
C08-10 SPAN CALIBRATION
The dot display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
*
C
A
L
I
B
.
S
P
A
N
W
E
I
G
H
T
The segment display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
C
0
8
-
1
0
#
#
#
#
#
*
*
*
*
*
###: Monitoring of A/D value
***: Monitoring of measuring value
Span adjustment (Calibration)
［ZERO］：Adjustment of zero point (Adjust the real zero to 20000 count)
［TARE］：Adjustment of span（60000 count／75000 count）
［’ ］：Span fine adjustment Plus compensation
［• ］：Span fine adjustment Minus compensation
30lb：1/60000
15kg：1/75000
