ISHIDA Uni-3 Service Manual

Chapter 7 ADJUSTMENT MODE
7-70 UNI-3 Service Manual
13.MODEL
The dot display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
C
1
3
M
O
D
E
L
The segment display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
C
1
3
M
O
D
E
L
Selects a model flag.
C13-01 MODEL SELECT
The dot display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
*
M
O
D
E
L
S
E
L
E
C
T
→
1
:
B
/
P
The segment display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
C
1
3
-
0
1
M
O
D
E
L
1
1: B/P
2: ELEVATOR
4: HANGING
Specifies the machine mode to accord the operation mode of the program with the installed hardware.
There are three main types of scales as shown below.
1: Bench/Pole (Display)
2: Elevated type
4: Hanging scale
If the machine model and the program settings are not accorded, the scale cannot be operated correctly. Make
sure to accord the mode.
