ISHIDA Uni-3 Service Manual

Chapter 6 SETUP MODE
6-2 UNI-3 Service Manual
1.MACHINE No.
The dot display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
B
0
1
M
A
C
H
I
N
E
N
O
.
[
C
O
M
M
S
]
The segment display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
B
0
1
M
A
C
H
I
N
E
N
O
[
C
O
M
M
S
]
Select the sub-menu tabs for the sub-menus under Machine Set.
1.BASIC *MACHINE SET Execute system setup.
Stand alone/Master/Satellite
*COMMUNICATION Execute online setup. Satellite only
Online/Offline
*PLU REFERENCE Specify PLU call recipient. Satellite only
Local Machine/Master Machine
*MACHINE NUMBER
Machine number
*NETWORK NUMBER
Network number
*MASTER PORT NUMBER
Master machine port number (socket transmission)
*SATELLITE PORT NUMBER
Satellite machine port number (socket transmission)
*MASTER IP ADDRESS
Master machine IP address
*PLU SYNC.
Product master sync. Master machine only
2.IP ADDR
*IP ADDRESS
LAN setup IP address
*SUBNET MASK
LAN setup Sub-net mask
*DEFAULT GATEWAY
LAN setup Gateway
3.PC COM *PC IP ADDRESS Specify IP address of PC in wh
ich SLP has been
installed.
*PORT NO Port number used for communication with SLP
Default value (8071)
*COM CHECK PERIOD(SEC)
SLP live or dead check: Period (seconds)
*COM CHECK TIME OUT(SEC)
SLP live or dead check: Time out time
*FTP USER
User name for FTP transmission
*FTP PASS
Password for FTP transmission
*PRESET FUNC
4.WiFi
*SECURITY
*KEY TYPE Encryption setup
ASCII/HEX (hexadecimal)
*SSID(WIRELESS NETWORK)
Enter from SSID editor.
*WEP KEY INDEX
Select 1~4.
