ISHIDA Uni-3 Service Manual

Chapter 2 ASSEMBLY DRAWINGS
2-4 UNI-3 Service Manual
Parts List (Bench Type L1)
NO. PARTS NAME Q'TY NO. PARTS NAME Q'TY
1 Sheet(Keysheet Protect BC-8000) 1 52 Bracket(Bobbin) 1
2 Edit-Keysheet(UNI-3 EU) 1 53 Spring(Bobbin) 1
3 Membrane Keypad(BC-8000) 1 54 Shaft(Bobbin) 1
4 PWB'PS-068'KEY(BC-8000) 1 55 Support(Sensor)-NL 1
5 Case(UNI-3 UL) 1 56 Axile Bush(BC-6000-NL) 32
6 Platter(SUS304 BC-8000) 1 57 Support(Roll)-NL 1
7 Guard(Platter BC-8000) 1 58 Cover(BC-6000-NL 1
8 Cover-Customer(BC-8000) 1 59 BUSH'LEFT' 2
9 Hens 1 60 Axis01(BC-6000-NL) 1
10 Support-Poweroutlet(BC-8000) 1 61 Axis02(UNI-3) 1
11 Support(platter Astra) 1 62 Shaft 1 1
12 RUBBER PLATE SUPPORT 4 63 FRAME'HEAD' 1
13
LOAD CELL
（
C2G1-25K-S18-25kg-350 NMB
）
1 64 BRACKET'HEAD' 1
14 BASE(Loadcell BC-8000) 1 65 Thermal head CHX56-9719A 1
15 HARNESS 'C3' POWER 1 66 BRACKET'LOCK' 1
16
POWER CORD HY-01/HY-02
（
3×0.75mm²×2m
）
USA
1 67 BRACKET'PUSH' 1
17 SWITCH（BR-22C-11L-S） 1 68 Axis-Hold(BC-6000 Printer) 1
18 Nameplate(UNI-3 L1BENCH USA) 1 69 TEAR BAR 1
19 Connector(UNI-3 UL) 1 70 Bracket(Sensor BC-6000-NL) 2
20 PWB'PS-990G-2'MAIN 2M(UNI-3) 1 71 Spring Coil 1 2
21 PWB, PS-067, A/D 1 72 Spring Coil 2 2
22 Cover(Base Port BC-8000) 1 73 LABEL SENSOR Assy 1
23 BASE02(BC-8000) 1 74 HARNESS 'S2' THERMAL HEAD 1
24 Bracket(Display-L1 BC-8000)
2
75 HARNESS 'S2' POWER 1
25
LCD DISPLAY MODULE
(BTD2301E-TDWC-G-B-A02)
2 76 HARNESS'C3'DISPLAY 1
26 Cover-PrinterFront(UNI-3 UL) 1 77 HARNESS'S2'DISPLAY 1
27 LEG
4
78 HARNESS 'S2' keyboard 1
28 BASE01(BC-8000) 1 79 HARNESS 'C3' POWER 1
29 POWER SUPPLY LSF10024 1 80 BREAKET(FOR PRINTER) 1
30 Cover-Printerside(UNI-3 UL) 1 81 Bracket(Magnet) 1
31 Printer Nameplate(NL)(English) 1 82 LABEL GND CORD 1
32 HINGE(Plastic) 2 83 BUSH(CSB-EPBF-0608-04) 1
33
Displaysheet
(UNI-3 L1B CUST-M30lb USA)
1 84 Bracket(Cutter) 1
34
Displaysheet
(UNI-3 L1 OP-M30lb USA)
1 85 Screw(UNI-3 Cutter) 2
35 MOTOR'STEPPING',49P048L0-00702 1 86 ZCAT1518-0730 1
36 Bracket Motor(BC-8000) 1 88 Bracket(Peel Sensor AC-4000B) 1
37
Bracket01
(Printer-Rewind BC-8000)
1 89 Peel Sensor 1
38 Axis-Rewind(BC-8000) 1 90 HARNESS PEEL SENSOR L-150mm 1
39 BUSH(CSB-EPBF-0507-04) 1 91 BUSH 1
40 OLTC6-1500B 1 92 Shaft(POM) 1
41 Gear-Rewind(BC-8000) 1 93 Breaket of peel off 1
42 3M-HTD-330 1 94 Breaket of Fixed 1
43 Gear Dual(BC-8000) 1 95 Lable Guide 1
44 Gear-Driver(BC-8000) 1
45 Cover(Gear-Driver BC-8000) 1
46 ROLLER'RUBBER' (BC-4000 NL) 1
73 LABEL SENSOR Assy
47 Frame(Printer BC-8000) 1 73.1 HARNESS,C5,LABEL SENSOR
48 LEVEL UNIT 07901 1 73.2 LED IR928-6C(E4 E5 E6)
49 HOLDER'GUIDE'LABEL 1 73.3 PHOTO TR PT928-6B(6-1 6-2 7-1)
50 LEVER'GUIDE'LABEL 1
51 HOLDER'LABEL' 1
