ISHIDA Uni-3 Service Manual

Chapter 2 ASSEMBLY DRAWINGS
2-6 UNI-3 Service Manual
Parts List (Pole Type L2)
NO. PARTS NAME Q'TY NO. PARTS NAME Q'TY
1 Sheet(Keysheet Protect BC-8000) 1 57 HOLDER'GUIDE'LABEL 1
2 Edit-Keysheet(UNI-3 EU) 1 58 LEVER'GUIDE'LABEL 1
3 Membrane Keypad(BC-8000) 1 59 HOLDER'LABEL' 1
4 PWB'PS-068'KEY(BC-8000) 1 60 Bracket(Bobbin) 1
5 Case(UNI-3 UL) 1 61 Spring(Bobbin) 1
6 Platter(SUS304 BC-8000) 1 62 Shaft(Bobbin) 1
7 Guard(Platter BC-8000) 1 63 Support(Sensor)-NL 1
8 Cover-Customer(UNI-3 UL) 1 64 Axile Bush(BC-6000-NL) 32
9 Hens 1 65 Support(Roll)-NL 1
10 Support-Poweroutlet(UNI-3 UL) 1 66 Cover(BC-6000-NL 1
11 Support(platter Astra) 1 67 BUSH'LEFT' 2
12 RUBBER PLATE SUPPORT 4 68 Axis01(BC-6000-NL) 1
13
LOAD CELL（C2G1-25K-S18-25kg-350 NMB）
1 69 Axis02(UNI-3) 1
14 BASE(Loadcell BC-8000) 1 70 Shaft 1 1
15 HARNESS 'C3' POWER 1 71 FRAME'HEAD' 1
16
POWER CORD HY-01/HY-02
（
3×0.75mm²×2m
）
USA
1 72 BRACKET'HEAD' 1
17 SWITCH（BR-22C-11L-S） 1 73 Thermal head CHX56-9719A 1
18 Nameplate(UNI-3 L2 USA-M30lb) 1 74 BRACKET'LOCK' 1
19 Connector(UNI-3 UL) 1 75 BRACKET'PUSH' 1
20 PWB'PS-990G-2'MAIN 2M(UNI-3) 1 76 Axis-Hold(BC-6000 Printer) 1
21 PWB, PS-067, A/D 1 77 TEAR BAR 1
22 Cover(Base Port BC-8000) 1 78 Bracket(Sensor BC-6000-NL) 2
23 BASE02(BC-8000) 1 79 Spring Coil 1 2
24 Bracket(Display-L2 BC-8000)
2
80 Spring Coil 2 2
25 DISPLAY 'LCD' DOT(SMMD0202-A-00-SPC) 2 81 LABEL SENSOR Assy 1
26 Cover-PrinterFront(UNI-3 UL) 1 82 HARNESS 'S2' THERMAL HEAD 1
27 LEG
4
83 HARNESS 'S2' POWER 1
28 BASE01(BC-8000) 1 84 HARNESS 'S2' LCD 1
29 POWER SUPPLY LSF10024 1 85 HARNESS S2 DISPLAY L2 1
30 Cover-Printerside(UNI-3 UL) 1 86 HARNESS 'S2' keyboard 1
31 Printer Nameplate(NL)(English) 1 87 HARNESS'C2'DISPLAY L2 1
32 HINGE(Plastic) 2 88 HARNESS 'C3' POWER 1
33 Bracket(Pole Base BC-8000) 1 89 BREAKET(FOR PRINTER) 1
34 Pole Base(BC-8000) 1 90 RESISTOR ASSY '' 1
35 Pole(BC-8000) 1 91 Bracket(Magnet) 1
36 Cover(Pole Base BC-8000) 1 92 LABEL GND CORD 1
37 Lock-nut(BC-8000) 1 93 BUSH(CSB-EPBF-0608-04) 1
38 DisplayCase-B(UNI-3 UL) 1 94 Bracket(Cutter) 1
39 DisplayCase-F(UNI-3 UL) 1 95 Screw(UNI-3 Cutter) 2
40 Displaysheet(UNI-3 L2 CUST-M30Lb USA) 1 96 ZCAR1518-0730 1
41 DisplayPanel(UNI-3 Cust) 1 98 Bracket(Peel Sensor AC-4000B) 1
42 Displaysheet(UNI-3 L2 OP-M30lb USA) 1 99 Peel Sensor 1
43 MOTOR'STEPPING',49P048L0-00702 1 100 HARNESS PEEL SENSOR L-150mm 1
44 Bracket Motor(BC-8000) 1 101 BUSH 1
45 Bracket01(Printer-Rewind BC-8000) 1 102 Shaft(POM) 1
46 Axis-Rewind(BC-8000) 1 103 Breaket of peel off 1
47 BUSH(CSB-EPBF-0507-04) 1 104 Breaket of Fixed 1
48 OLTC6-1500B 1 105 Lable Guide 1
49 Gear-Rewind(BC-8000) 1
50 3M-HTD-330 1
51 Gear Dual(BC-8000) 1
52 Gear-Driver(BC-8000) 1
81 LABEL SENSOR Assy
53 Cover(Gear-Driver BC-8000) 1 81.1 HARNESS,C5,LABEL SENSOR
54 ROLLER'RUBBER' (BC-4000 NL) 1 81.2 LED IR928-6C(E4 E5 E6)
55 Frame(Printer BC-8000) 1 81.3 PHOTO TR PT928-6B(6-1 6-2 7-1)
56 LEVEL UNIT 07901 1
