Chapter 4 ELECTRICAL SIGNALS

4-4 UNI-3 Service Manual

XJ21

No. Signal Name Direction Opposite Side

1,2,3,4,8 A/D board control signal <-->

A/D board PS-067*

5,9 GND -

6 DC+5V -

7,11 Not connected

10 DC+12V for A/D board -

XJ22

No. Signal Name Direction Opposite Side

1 Battery+ -

Jumper 2 Back up power -

3 Not connected

XJ25

No. Signal Name Direction Opposite Side

1 Vbus -

USB memory

2 D- <-->

3 D+ <-->

4 GND -

XJ101

No. Signal Name Direction Opposite Side

1 DC+5V -

Scanner

2 GND -

3 TxD ->

4 RTS ->

5 RxD <-

6 CTS <-
