CCI.TECU – Operation
4.3.1 Add tractor
To add a tractor proceed as follows:
1. Press the "Add Tractor" button (F10) on the touchscreen.
A detailed view of a new tractor is opened.
2. In the detailed view, select the desired tab. To do so, press on the tab icon on
the touchscreen or change using the buttons "To the left" (F8) and "To the
right" (F2) between the tabs.
3. Enter the new values and execute the new settings.
The processing options for the individual tabs can be consulted in chapter
4.3.3.
Note
Upon delivery there is already an unnamed tractor in the list with some default
settings. Please modify the settings (see chapter 4.3.3).
4.3.2 Edit tractor
To edit a stored tractor proceed as follows:
1. In the list of tractors select the tractor whose information is to be changed.
To do so, on the touchscreen press the button with the tractor name or turn
the scroll wheel until the button is highlighted in white and then press on the
scroll wheel.
Once the button is highlighted you can, alternatively, also press the "OK"
(F6) button.
The context menu opens.
2. Press on the "Edit" button on the touchscreen or turn the scroll wheel until
the button is highlighted in white and then press on the scroll wheel.
A detailed view of the tractor is opened.
3. Select all tabs to be modified in the detailed view. To do so, press on the tab
icon on the touchscreen or change using the buttons "To the left" (F8) and
"To the right" (F2) between the tabs.
4. Enter the new value and execute the new setting.
The processing options for the individual tabs can be consulted in chapter
4.3.3.
16
